Kubernetes CSI Driver#

The cunoFS CSI Driver facilitates seamless integration of your cloud storage services (Amazon S3, Google Cloud, and Azure Cloud) within a Kubernetes cluster. The driver is available through Helm under oci://registry-1.docker.io/cunofs/cunofs-csi-chart. More information can be found on docker hub.

Install#

Ensure that Helm is installed. If not, follow the Helm installation guide
Deploy the cunoFS CSI Driver:

helm install cunofs-csi-chart oci://registry-1.docker.io/cunofs/cunofs-csi-chart \
  --set cunofsLicense.license="<license-text>"                                   \
  --set credsToImport="{<credentials-1>,<credential-2>, ... ,<credentials-N>}"

--set cunofsLicense.license: (required) cunoFS license [more details]
--set credsToImport: (optional) cloud credentials [more details]

Display the status of the cunoFS CSI Driver resources:

kubectl get all -l app.kubernetes.io/name=cunofs-csi-driver

Note

For security reasons, helm doesn’t allow access to files via paths. Therefore, you need to provide the credential file contents credsToImport, and not the path. To ensure that the cloud credentials are passed correctly, please provide them in base64 encoding. For example:

--set credsToImport="{$(cat creds-1.txt | base64), $(cat creds-2.json | base64)}"

Update#

Upgrade to the latest version:

helm upgrade --reuse-values cunofs-csi-chart oci://registry-1.docker.io/cunofs/cunofs-csi-chart

You can append the --version <version> to upgrade to a specific version.

Uninstall#

helm uninstall cunofs-csi-chart

Storage allocation#

The cunoFS CSI Driver support the following strategies:

Static storage provisioning
Dynamic storage provisioning

Static provisioning#

To allocate storage statically, define one or more PV (PersistentVolume) providing the bucket details and options:

PV manifest defined by cluster admin#

apiVersion: v1
kind: PersistentVolume
metadata:
  name: cunofs-pv
spec:
  capacity:
    storage: 16Ei # ignored but required
  accessModes:
    - ReadWriteOncePod # Currently only support "ReadWriteOncePod"
  csi:
    driver: cunofs.csi.com # required
    volumeHandle: cunofs-csi-driver-volume
    volumeAttributes:
      root: "/cuno/s3/bucket/subdirectory/other_subdirectory" # optional
      posix: "true" # optional
      allow_root: "false" # optional
      allow_other: "true" # optional
      auto_restart: "true" # optional
      readonly: "true" # optional

Then, define a PVC (PersistentVolumeClaim):

PVC manifest defined by cluster admin#

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: cunofs-pvc
spec:
  accessModes:
    - ReadWriteOncePod
  storageClassName: "" # ensures that no dynamic provisioning occurs
  resources:
    requests:
      storage: 16Ei # ignored but required
  volumeName: cunofs-pv # PV metadata.name

Finally, cluster users can mount the PVC:

Pod manifest defined by cluster user#

apiVersion: v1
kind: Pod
metadata:
  name: consumer-pod
spec:
  containers:
    - name: cunofs-app
      image: centos
      command: ["/bin/sh"]
      args: ["-c", "echo 'Hello from the container!' > /data/s3/cuno-csi-testing/K8s_$(date -u).txt; tail -f /dev/null"]
      volumeMounts:
        - name: persistent-storage
          mountPath: /data
  volumes:
    - name: persistent-storage
      persistentVolumeClaim:
        claimName: cunofs-pvc # PVC metadata.name

Dynamic provisioning#

To allocate storage dynamically, define a StorageClass providing the bucket details and options:

StorageClass manifest defined by cluster admin#

apiVersion: storage.K8s.io/v1
kind: StorageClass
metadata:
  name: cunofs-storageclass
provisioner: cunofs.csi.com
  reclaimPolicy: Retain # default is Delete
  parameters:
    cloud-type: s3 # requires either of s3/az/gs
    bucket: cuno-csi-testing # requires bucket that already exists
    bucket-subdir: test_kubernetes # optional
    # Options passed down to the PV:
    posix: "true" # optional
    allow_root: "false" # optional
    allow_other: "true" # optional
    auto_restart: "true" # optional
    readonly: "true" # optional

Then, define a PVC which has a reference to the StorageClass:

PVC manifest defined by cluster admin#

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: cunofs-pvc
spec:
  accessModes:
    - ReadWriteOncePod
  storageClassName: "cunofs-storageclass" # StorageClass metadata.name
  resources:
    requests:
      storage: 16Ei # ignored but required

Cluster users can mount the PVC similarly to the static allocation case:

Pod manifest defined by cluster user#

apiVersion: v1
kind: Pod
metadata:
  name: consumer-pod
spec:
  containers:
    - name: cunofs-app
      image: centos
      command: ["/bin/sh"]
      args: ["-c", "echo 'Hello from the container!' > /data/s3/cuno-csi-testing/K8s_$(date -u).txt; tail -f /dev/null"]
      volumeMounts:
        - name: persistent-storage
          mountPath: /data
  volumes:
    - name: persistent-storage
      persistentVolumeClaim:
        claimName: cunofs-pvc # PVC metadata.name

Alternatively, cluster users can create a generic inline volume which doesn’t require a PVC:

Pod manifest defined by cluster user#

apiVersion: v1
kind: Pod
metadata:
  name: consumer-pod-dyn-inline
spec:
  containers:
    - name: cunofs-app-inline
      image: centos
      command: ["/bin/sh"]
      args: ["-c", "echo 'Hello from the container, inline volume!' >> /data/generic-inline-k8s_$(date -u).txt; tail -f /dev/null"]
      volumeMounts:
        - name: inline-cuno-storage
          mountPath: /data
  volumes:
    - name: inline-cuno-storage
      ephemeral:
        volumeClaimTemplate:
          metadata:
            labels:
              type: my-inline-volume
          spec:
            accessModes: [ "ReadWriteOncePod" ]
            storageClassName: cunofs-storageclass # StorageClass metadata.name
            resources:
              requests:
                storage: 16Ei # ignored but required

Note

The current version of cunoFS CSI Driver does not support CSI inline volumes

Configuration#

This section offers additional details about the configuration options for the cunoFS CSI driver.

Helm chart#

The Helm chart can be also installed, configured and deployed manually.

Download the chart manually:

helm pull --untar oci://registry-1.docker.io/cunofs/cunofs-csi-chart

Set the cunofsLicense.license variable and import the cloud credentials:

# values.yaml file
cunofsLicense:
  license: "<your license key>"
credsToImport:
  - "<credential-1>"
  - "<credential-2>"
  - "<..>"
  - "<credential-N>"

Finally, install the local chart by pointing to its directory:

helm install cunofs-csi-chart <path-to-chart>

Available options:

Yaml Value	Description	Default Value
driverName	Optionally change the name of the deployed driver. Only useful if you want to deploy several instances of the driver.	cunofs.csi.com
cunofsCSIimage.pullPolicy	Specifies how the docker image is deployed onto the Node and Controller. Only useful to change if self-hosting the docker image.	Always
cunofsCSIimage.name	Specifies the cunoFS CSI docker image. Only useful to change if self-hosting the docker image under a different name (Note: do not include the version here).	cunofs/cunofs_csi
cunofsCSIimage.version	Specifies the docker image’s version. No need to change it unless you have a good reason to.	<equal to chart version>
cunofsLicense.license	The license used for activating cunoFS on the Driver. It needs to be a valid Professional or Enterprise license.	<empty>
credsToImport	Yaml array that you can populate with your s3/az/gs credential files.	<emtpy>
rbac.useRBAC	Enables out of the box support for RBAC clusters (deploys the required ClusterRole/ClusterRoleBinding).	true
eks.iam_arn	On Amazon EKS, support for importing buckets via IAM roles.	<empty>

PersistentVolume options#

Yaml Value	Description
metadata.name	Can be any name as long as it’s unique
spec.capacity.storage	This value is ignored, but is required to be set by the CSI specification
spec.csi.driver	It’s required to set this to “cunofs.csi.com”
spec.csi.volumeHandle	Name of the volume, needs to be unique
spec.accessModes	We currently only support “ReadWriteOncePod”
spec.csi.volumeAttributes.root	This is the cloud URI tht will be mounted to the target mountpath. If not specified, you can access s3, az and gz through the target + ‘/az’ or ‘/gs’ or ‘/s3’ directories
spec.csi.volumeAttributes.posix	Set it to “true” to enforce strict posix mode for cunoFS
spec.csi.volumeAttributes.allow_root:	Set it to “true” to allow only the root user to access the mount. Overrides allow_other
spec.csi.volumeAttributes.allow_other:	Set it to “true” to allow all users to use the mount (recommended)
spec.csi.volumeAttributes.auto_restart:	Set it to “true” to automatically restart the cunoFS mount if an error occurs
spec.csi.volumeAttributes.readonly:	Set it to “true” to mount the volume as read only

StorageClass options#

Yaml Value	Description
metadata.name	Can be any name as long as it’s unique
provisioner	Needs to be “cunofs.csi.com”
reclaimPolicy	“Retain” will not delete the generated PVs and their storage when the PVCs go out of scope, “Delete” will
parameters.cloud-type	Can be “s3”, “az” or “gs”
parameters.bucket	The bucket used to create volumes
parameters.bucket-subdir	Optional. The subdirectory of the bucket where the PVCs will get generated. Can be nested subdirectories like “dir/other_dir/yet_another_dir”
parameters.posix, parameters.allow_root, parameters.allow_other, parameters.auto_restart, parameters.readonly	These options will be passed down to the generated PV and behave the same way as described in the PersistentVolume options

RBAC Support#

By default, the cunoFS CSI Driver deploys a ServiceAccount, ClusterRole and ClusterRoleBinding to support Role-Based Access Control (RBAC) out of the box.

They are respectively deployed under the following names: <release name>-serviceaccount, <release name>-clusterrole and <release name>-clusterrolebinding.

This means that we support Amazon EKS out-of-the-box.

You can choose not to deploy the ClusterRole and ClusterRoleBinding by setting the rbac.useRBAC property to false in the values.yaml file:

helm install cunofs-csi-chart oci://registry-1.docker.io/cunofs/cunofs-csi-chart \
  --set cunofsLicense.license="<license-text>"                                   \
  --set credsToImport="{<credentials-1>,<credential-2>, ... ,<credentials-N>}"   \
  --set rbac.useRBAC=false

EKS IAM roles#

The cunoFS CSI Driver supports importing buckets through IAM roles on Amazon EKS. Simply define the IAM role’s ARN by setting the eks.iam_arn property in the values.yaml file or by passing it to helm through --set while deploying it:

helm install cunofs-csi-chart oci://registry-1.docker.io/cunofs/cunofs-csi-chart \
  --set cunofsLicense.license="<license-text>"                                   \
  --set eks.iam_arn="<your IAM role's ARN>"

You should be able to access any buckets that is permitted to the IAM role without extra credentials.

Note

Make sure that the IAM role you provide has the correct permissions, including listing S3 buckets and accessing them.

Technical Details#

The cunoFS CSI Driver abides by the Kubernetes Container Storage Interace standard.

It implements the Node, Controller and Identity plugins and uses sidecar containers for simplifying its deployment and maintenance.

The CSI Driver is shipped into one binary, which can act as the Node or the Controller depending on the context (how it’s deployed and which sidecar containers are connected). The helm chart deploys docker containers that have this binary preinstalled. The Node plugin refers to the ability to mount and organise existing PersistentVolumes on a Kubernetes node. The Controller plugin implements the ability to create PersistentVolumes dynamically through a StorageClass.

The Node and the Controller need to handle logic at different levels:

The Node plugin needs to be deployed on every K8s Node, since it handles mounting logic that’s specific to each machine on which the application containers run. Therefore, it is deployed via a K8s DaemonSet. Additionally, these sidecar containers are shipped with the Node:

Liveness Probe
This sidecar container ensures that the driver remains responsive, and replaces the driver container on crash.

Node Driver Registrar
This sidecar container registers the driver to the kubelet to simplify its discovery and communication.
The Controller plugin needs to be unique across a Kubernetes cluster, since it handles the lifecycle of PersistentVolumes, which are K8s global objects. It is therefore managed through a K8s StatefulSet:

Liveness Probe
This sidecar container, like with the Node plugin, ensures that the driver remains responsive, and replaces the driver container on crash.

External Provisioner
This sidecar container helps the driver interacting with the K8s API by listening to volume provisioning-related calls.

During the deployment, the cunoFS CSI Driver deploys the cunoFS license and cloud credentials as Secrets. The license Secret is imported by the Node and the Controller through an environment variable.

The credential Secret is mounted to the Node and the Controller through a Projected Volume and sequentially imported by cunoFS.

Limitations#

Not every existing K8s optional feature is currently implemented in this driver. Please contact support@cuno.io for specific feature inquiries.

Due to the internals of K8s, the cunoFS CSI Driver makes use of cunoFS mount as a backend instead of regular cunoFS. This means that performance will be high, but not always as high as a regular cunoFS installation.
Not every cunoFS option is currently available for use in the driver. Please refer to the configuration section for the available options.
There currently isn’t a way of easily using cunoFS Fusion with this driver.
Currently, only the ReadWriteOncePod access mode is supported. You can always create PVs with the same root, although this can be a bit more verbose than rusing the same PVC or PV.
The cunoFS CSI Driver currently doesn’t support CSI Ephemeral Volumes, raw block volumes, volume snapshotting, volume expansion, volume cloning and volume topology options.
